#include <NetworkTableNode.h>

Inheritance diagram for NetworkTableNode:

Collaboration diagram for NetworkTableNode:

Public Member Functions
AbstractNetworkTableEntryStore &	GetEntryStore ()

void	PutBoolean (std::string &name, bool value)

bool	GetBoolean (std::string &name)

void	PutDouble (std::string &name, double value)

double	GetDouble (std::string &name)

void	PutString (std::string &name, std::string &value)

std::string &	GetString (std::string &name)

void	PutComplex (std::string &name, ComplexData &value)

void	retrieveValue (std::string &name, ComplexData &externalData)

void	PutValue (std::string &name, NetworkTableEntryType *type, EntryValue value)

void	PutValue (NetworkTableEntry *entry, EntryValue value)

EntryValue	GetValue (std::string &name)

bool	ContainsKey (std::string &key)

virtual void	Close ()=0

void	AddConnectionListener (IRemoteConnectionListener *listener, bool immediateNotify)

void	RemoveConnectionListener (IRemoteConnectionListener *listener)

void	FireConnectedEvent ()

void	FireDisconnectedEvent ()

void	AddTableListener (ITableListener *listener, bool immediateNotify)

void	RemoveTableListener (ITableListener *listener)

void	FireTableListeners (std::string &key, EntryValue value, bool isNew)

Public Member Functions inherited from IRemote
virtual bool	IsConnected ()=0

virtual bool	IsServer ()=0

Protected Member Functions
	NetworkTableNode (AbstractNetworkTableEntryStore &entryStore)

Protected Attributes
AbstractNetworkTableEntryStore &	entryStore

Detailed Description

represents a node (either a client or a server) in a network tables 2.0
implementers of the class must ensure that they call init(NetworkTableTransactionPool, AbstractNetworkTableEntryStore) before calling any other methods on this class

Author: Mitchell

Definition at line 32 of file NetworkTableNode.h.

Member Function Documentation

void NetworkTableNode::AddConnectionListener	(	IRemoteConnectionListener *	listener,
		bool	immediateNotify
	)

virtual

Register an object to listen for connection and disconnection events

Parameters

listener	the listener to be register
immediateNotify	if the listener object should be notified of the current connection state

Implements IRemote.

Definition at line 134 of file NetworkTableNode.cpp.

virtual void NetworkTableNode::Close ( )

pure virtual

close all networking activity related to this node

Implemented in NetworkTableServer, and NetworkTableClient.

bool NetworkTableNode::ContainsKey ( std::string & key )

Parameters

key	the key to check for existence

Returns: true if the table has the given key

Definition at line 130 of file NetworkTableNode.cpp.

void NetworkTableNode::FireConnectedEvent ( )

virtual

called when something is connected

Implements ClientConnectionListenerManager.

Definition at line 146 of file NetworkTableNode.cpp.

void NetworkTableNode::FireDisconnectedEvent ( )

virtual

called when something is disconnected

Implements ClientConnectionListenerManager.

Definition at line 150 of file NetworkTableNode.cpp.

AbstractNetworkTableEntryStore & NetworkTableNode::GetEntryStore ( )

Returns: the entry store used by this node

Definition at line 22 of file NetworkTableNode.cpp.

void NetworkTableNode::PutValue	(	std::string &	name,
		NetworkTableEntryType *	type,
		EntryValue	value
	)

Put a value with a specific network table type

Parameters

name	the name of the entry to associate with the given value
type	the type of the entry
value	the actual value of the entry

Definition at line 85 of file NetworkTableNode.cpp.

void NetworkTableNode::RemoveConnectionListener ( IRemoteConnectionListener * listener )

virtual

Unregister a listener from connection events

Parameters

listener the listener to be unregistered

Implements IRemote.

Definition at line 141 of file NetworkTableNode.cpp.

The documentation for this class was generated from the following files:
