Solenoid Class Reference

#include <Solenoid.h>

Inheritance diagram for Solenoid:
Collaboration diagram for Solenoid:

Public Member Functions

 Solenoid (uint32_t channel)

 Solenoid (uint8_t moduleNumber, uint32_t channel)

virtual ~Solenoid ()

virtual void Set (bool on)

virtual bool Get ()

void ValueChanged (ITable *source, const std::string &key, EntryValue value, bool isNew)

void UpdateTable ()

void StartLiveWindowMode ()

void StopLiveWindowMode ()

std::string GetSmartDashboardType ()

void InitTable (ITable *subTable)

ITableGetTable ()

- Public Member Functions inherited from SolenoidBase
virtual ~SolenoidBase ()

uint8_t GetAll ()

- Public Member Functions inherited from SensorBase
 SensorBase ()

virtual ~SensorBase ()

- Public Member Functions inherited from ErrorBase
virtual ErrorGetError ()
 Retrieve the current error. Get the current error information associated with this sensor.

virtual const ErrorGetError () const

virtual void SetErrnoError (const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const
 Set error information associated with a C library call that set an error to the "errno" global variable. More...

virtual void SetImaqError (int success, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const
 Set the current error information associated from the nivision Imaq API. More...

virtual void SetError (Error::Code code, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const
 Set the current error information associated with this sensor. More...

virtual void SetWPIError (const char *errorMessage, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const
 Set the current error information associated with this sensor. More...

virtual void CloneError (ErrorBase *rhs) const

virtual void ClearError () const
 Clear the current error information associated with this sensor.

virtual bool StatusIsFatal () const
 Check if the current error code represents a fatal error. More...


Additional Inherited Members

- Static Public Member Functions inherited from SensorBase
static void DeleteSingletons ()

static uint32_t GetDefaultAnalogModule ()

static uint32_t GetDefaultDigitalModule ()

static uint32_t GetDefaultSolenoidModule ()

static bool CheckAnalogModule (uint8_t moduleNumber)

static bool CheckDigitalModule (uint8_t moduleNumber)

static bool CheckPWMModule (uint8_t moduleNumber)

static bool CheckRelayModule (uint8_t moduleNumber)

static bool CheckSolenoidModule (uint8_t moduleNumber)

static bool CheckDigitalChannel (uint32_t channel)

static bool CheckRelayChannel (uint32_t channel)

static bool CheckPWMChannel (uint32_t channel)

static bool CheckAnalogChannel (uint32_t channel)

static bool CheckSolenoidChannel (uint32_t channel)

- Static Public Member Functions inherited from ErrorBase
static void SetGlobalError (Error::Code code, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber)

static void SetGlobalWPIError (const char *errorMessage, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber)

static ErrorGetGlobalError ()

- Static Public Attributes inherited from SensorBase
static const uint32_t kSystemClockTicksPerMicrosecond = 40

static const uint32_t kDigitalChannels = 14

static const uint32_t kAnalogChannels = 8

static const uint32_t kAnalogModules = 2

static const uint32_t kDigitalModules = 2

static const uint32_t kSolenoidChannels = 8

static const uint32_t kSolenoidModules = 2

static const uint32_t kPwmChannels = 10

static const uint32_t kRelayChannels = 8

static const uint32_t kChassisSlots = 8

- Protected Member Functions inherited from SolenoidBase
 SolenoidBase (uint8_t moduleNumber)

void Set (uint8_t value, uint8_t mask)

- Protected Member Functions inherited from SensorBase
void AddToSingletonList ()

- Protected Member Functions inherited from ErrorBase
 ErrorBase ()
 Initialize the instance status to 0 for now.

- Protected Attributes inherited from SolenoidBase
uint32_t m_moduleNumber
 Slot number where the module is plugged into the chassis.

- Protected Attributes inherited from ErrorBase
Error m_error

- Static Protected Attributes inherited from SolenoidBase
static Resourcem_allocated = NULL

- Static Protected Attributes inherited from ErrorBase
static SEM_ID _globalErrorMutex = semMCreate(SEM_Q_PRIORITY | SEM_DELETE_SAFE | SEM_INVERSION_SAFE)

static Error _globalError


Detailed Description

Solenoid class for running high voltage Digital Output (9472 module).

The Solenoid class is typically used for pneumatics solenoids, but could be used for any device within the current spec of the 9472 module.

Definition at line 21 of file Solenoid.h.

Constructor & Destructor Documentation

Solenoid::Solenoid ( uint32_t  channel)
explicit

Constructor.

Parameters
channelThe channel on the solenoid module to control (1..8).

Definition at line 49 of file Solenoid.cpp.

Solenoid::Solenoid ( uint8_t  moduleNumber,
uint32_t  channel
)

Constructor.

Parameters
moduleNumberThe solenoid module (1 or 2).
channelThe channel on the solenoid module to control (1..8).

Definition at line 62 of file Solenoid.cpp.

Solenoid::~Solenoid ( )
virtual

Destructor.

Definition at line 72 of file Solenoid.cpp.

Member Function Documentation

bool Solenoid::Get ( )
virtual

Read the current value of the solenoid.

Returns
The current value of the solenoid.

Definition at line 99 of file Solenoid.cpp.

std::string Solenoid::GetSmartDashboardType ( )
virtual
Returns
the string representation of the named data type that will be used by the smart dashboard for this sendable

Implements Sendable.

Definition at line 131 of file Solenoid.cpp.

ITable * Solenoid::GetTable ( )
virtual
Returns
the table that is currently associated with the sendable

Implements Sendable.

Definition at line 140 of file Solenoid.cpp.

void Solenoid::InitTable ( ITable subtable)
virtual

Initializes a table for this sendable object.

Parameters
subtableThe table to put the values in.

Implements Sendable.

Definition at line 135 of file Solenoid.cpp.

void Solenoid::Set ( bool  on)
virtual

Set the value of a solenoid.

Parameters
onTurn the solenoid output off or on.

Definition at line 85 of file Solenoid.cpp.

void Solenoid::StartLiveWindowMode ( )
virtual

Start having this sendable object automatically respond to value changes reflect the value on the table.

Implements LiveWindowSendable.

Definition at line 117 of file Solenoid.cpp.

void Solenoid::StopLiveWindowMode ( )
virtual

Stop having this sendable object automatically respond to value changes.

Implements LiveWindowSendable.

Definition at line 124 of file Solenoid.cpp.

void Solenoid::UpdateTable ( )
virtual

Update the table for this sendable object with the latest values.

Implements LiveWindowSendable.

Definition at line 111 of file Solenoid.cpp.

void Solenoid::ValueChanged ( ITable source,
const std::string &  key,
EntryValue  value,
bool  isNew
)
virtual

Called when a key-value pair is changed in a ITable WARNING: If a new key-value is put in this method value changed will immediatly be called which could lead to recursive code

Parameters
sourcethe table the key-value pair exists in
keythe key associated with the value that changed
valuethe new value
isNewtrue if the key did not previously exist in the table, otherwise it is false

Implements ITableListener.

Definition at line 107 of file Solenoid.cpp.


The documentation for this class was generated from the following files:
