#include <DigitalSource.h>
Public Member Functions | |
virtual | ~DigitalSource () |
virtual uint32_t | GetChannelForRouting ()=0 |
virtual uint32_t | GetModuleForRouting ()=0 |
virtual bool | GetAnalogTriggerForRouting ()=0 |
virtual void | RequestInterrupts (tInterruptHandler handler, void *param)=0 |
Asynchronus handler version. | |
virtual void | RequestInterrupts ()=0 |
Synchronus Wait version. | |
Public Member Functions inherited from InterruptableSensorBase | |
virtual void | CancelInterrupts () |
Free up the underlying chipobject functions. More... | |
virtual void | WaitForInterrupt (float timeout) |
Synchronus version. More... | |
virtual void | EnableInterrupts () |
Enable interrupts - after finishing setup. More... | |
virtual void | DisableInterrupts () |
Disable, but don't deallocate. More... | |
virtual double | ReadInterruptTimestamp () |
Return the timestamp for the interrupt that occurred. More... | |
Public Member Functions inherited from SensorBase | |
SensorBase () | |
virtual | ~SensorBase () |
Public Member Functions inherited from ErrorBase | |
virtual Error & | GetError () |
Retrieve the current error. Get the current error information associated with this sensor. | |
virtual const Error & | GetError () const |
virtual void | SetErrnoError (const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const |
Set error information associated with a C library call that set an error to the "errno" global variable. More... | |
virtual void | SetImaqError (int success, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const |
Set the current error information associated from the nivision Imaq API. More... | |
virtual void | SetError (Error::Code code, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const |
Set the current error information associated with this sensor. More... | |
virtual void | SetWPIError (const char *errorMessage, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) const |
Set the current error information associated with this sensor. More... | |
virtual void | CloneError (ErrorBase *rhs) const |
virtual void | ClearError () const |
Clear the current error information associated with this sensor. | |
virtual bool | StatusIsFatal () const |
Check if the current error code represents a fatal error. More... | |
Additional Inherited Members | |
Static Public Member Functions inherited from SensorBase | |
static void | DeleteSingletons () |
static uint32_t | GetDefaultAnalogModule () |
static uint32_t | GetDefaultDigitalModule () |
static uint32_t | GetDefaultSolenoidModule () |
static bool | CheckAnalogModule (uint8_t moduleNumber) |
static bool | CheckDigitalModule (uint8_t moduleNumber) |
static bool | CheckPWMModule (uint8_t moduleNumber) |
static bool | CheckRelayModule (uint8_t moduleNumber) |
static bool | CheckSolenoidModule (uint8_t moduleNumber) |
static bool | CheckDigitalChannel (uint32_t channel) |
static bool | CheckRelayChannel (uint32_t channel) |
static bool | CheckPWMChannel (uint32_t channel) |
static bool | CheckAnalogChannel (uint32_t channel) |
static bool | CheckSolenoidChannel (uint32_t channel) |
Static Public Member Functions inherited from ErrorBase | |
static void | SetGlobalError (Error::Code code, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) |
static void | SetGlobalWPIError (const char *errorMessage, const char *contextMessage, const char *filename, const char *function, uint32_t lineNumber) |
static Error & | GetGlobalError () |
Static Public Attributes inherited from SensorBase | |
static const uint32_t | kSystemClockTicksPerMicrosecond = 40 |
static const uint32_t | kDigitalChannels = 14 |
static const uint32_t | kAnalogChannels = 8 |
static const uint32_t | kAnalogModules = 2 |
static const uint32_t | kDigitalModules = 2 |
static const uint32_t | kSolenoidChannels = 8 |
static const uint32_t | kSolenoidModules = 2 |
static const uint32_t | kPwmChannels = 10 |
static const uint32_t | kRelayChannels = 8 |
static const uint32_t | kChassisSlots = 8 |
Protected Member Functions inherited from InterruptableSensorBase | |
void | AllocateInterrupts (bool watcher) |
Protected Member Functions inherited from SensorBase | |
void | AddToSingletonList () |
Protected Member Functions inherited from ErrorBase | |
ErrorBase () | |
Initialize the instance status to 0 for now. | |
Protected Attributes inherited from InterruptableSensorBase | |
tInterrupt * | m_interrupt |
tInterruptManager * | m_manager |
uint32_t | m_interruptIndex |
Protected Attributes inherited from ErrorBase | |
Error | m_error |
Static Protected Attributes inherited from ErrorBase | |
static SEM_ID | _globalErrorMutex = semMCreate(SEM_Q_PRIORITY | SEM_DELETE_SAFE | SEM_INVERSION_SAFE) |
static Error | _globalError |
DigitalSource Interface. The DigitalSource represents all the possible inputs for a counter or a quadrature encoder. The source may be either a digital input or an analog input. If the caller just provides a channel, then a digital input will be constructed and freed when finished for the source. The source can either be a digital input or analog trigger but not both.
Definition at line 19 of file DigitalSource.h.
|
virtual |
DigitalSource destructor.
Definition at line 12 of file DigitalSource.cpp.
